LKS06 Series

LKS06 Series MCU is a Motion Control Series Chip specially designed for motor driven market by Ling Gu Wong-core. Integrated Instrument-level Full Differential Programmable Gain Amplifier + Differential ADC to process positive and negative signals without voltage bias; Integrated synchronous dual sampling 3Msps 12bit high speed ADC, integrated full temperature range 5/1000 voltage reference source; Integrates 96MHz 32BIT MCU, divides, and calculates the power within 100ns; The operating temperature range is -40~105℃, and the clock deviation of the internal RC is within 1%. The chip has passed HBM 6KV ESD test and 15KV non-contact air electrostatic discharge test.
