LKS05 Series

LKS05 series MCU is a cost-effective motion control chip for the motor drive market. Integrated Instrument-level Full Differential Programmable Gain Amplifier + Differential ADC to process positive and negative signals without voltage bias; Integrated synchronous dual sampling 3Msps 12BIT high speed ADC, integrated full temperature range 0.5% voltage reference source; Integrate 96MHz 32bit CPU, trigonometric function operation, square operation completed in 100ns; The operating temperature range is -40~105℃, and the clock deviation of the internal RC is within 1%. LKS05 series MCUs still have an excellent performance-price ratio while providing the necessary resources for the application of motor control.
